Mudkjøler

Capacity: 2 x 100m3/h (2 x 440gpm) *
Working pressure: 6 bar.
Process temperature: 120 °C (max 130 °C).
Lifting frame: DNV 2.7-3.
Standards: Zone 2 – PED – NORSOK Z-015
Instrumentation: Manometer & termometer on each nozzle.
Valves: Manual butterfly valves on each nozzle.
Heat Exchanger: 2 ea. Pleat ® type DN 125 x 6
Interface: Process: DN 150 or 200. Cooling Medium DN 150.
Cooling Medium: Seawater Typically 10-20 °C inlet, max 35°C as coolant.
LWH – Area: 1640 mm x 1200 mm x 2050 mm. A = 1,97m²
Weight: 2450 kg

* For optimum turbulent flow: Flow range ea. side 80-200m³/hour with single pass flow. With double pass plate, 40-100m³/hour.

Våre unike patenterte Pleat kjøleteknologi som gir brukere av dette produktet et fortinn i forhold til tradisjonelle løsninger.

  • FULLY REDUNDANT SYSTEM = NO DOWNTIME
  • 200 m³/h AND 6-8MW OF COOLING = COOL THE MOST DEMANDING HPHT WELLS
  • 1.9 m2 FOOTPRINT = EXTREME DECK SPACE SAVING
  • CAN BE POSITIONED WITH PALLET TROLLEYS = HUGE INSTALLATION TIME-SAVING

Ta kontakt for mer informasjon om de utallige fordelene med denne teknologien
